Laboratory of Electromagnetic Compatibility

  • Pre-compliance tests following most of the harmonised EU standards.
  • Electromagnetic Compatibility and Signal Integrity problems solution.
Type Experimental and didactic laboratory
Site Technological center of Alessandria: code Al_MIC01;XPTE; B004
Phone 0131 229321
Fax 0131 229399
E-mail fausto.franchini@polito.it
Dimension 85 mq
Equipment
  • Rohde & Schwarz ESBI – EMI Reciever 20Hz - 5GHz
  • MEB SMV4 – EMI Reciever 9kHz - 1GHz
  • Rohde & Schwarz SML03 – RF Generator 9kHz - 3,3GHz
  • Rohde & Schwarz SMY01 – RF Generator 9kHz - 1040MHz
  • Rohde & Schwarz NRVD – RF Wattmeter
  • Teseo SOPM03 – RF Wattmeter
  • Rohde & Schwarz HL562 – Antenna 30 MHz – 3 GHz
  • Laplace RF300 Triple Loop – Antenna 9 kHz – 30 MHz
  • Amplifier Research 200W1000M7A – RF Amplifier 200 W 1 GHz
  • Amplifier Research 30S1G3 – RF Amplifier 30W 3GHz
  • Amplifier Research 75A250 – RF Amplifier 75W 250MHz
  • Teseo AN25A3PH – LISN
  • MEB KEMZ 801 – EM Clamp
  • MEB CDN Mx – Coupling/Decoupling Networks
  • Schaffner CIP9136 – Current Injection Clamp
  • Compliance Design ESD2000i – ESD Generator
  • Compliance Design EFT/B100 – Burst Generator
  • Compliance Design M5+3CN – Surge Generator
  • PMM 8053, OR02 – Field meters
  • PMM EP330, EHP50A, HP032 – Isotropic Electric and Magnetic Field Probes
  • Holaday HI-4422 – Isotropic electric field probe 10kHz-1GHz
  • Schaffner NGS5500 – Automotive standard conducted disturbances generator
  • Emco 5400 – GTEM Cell
  • Magnetic Instruments Model 809 – 3T Gaussmeter
